Nanocrystalline FeCuNbSiB powder core (50.80 x 31.75 x 14.46 mm, permeability 75)
Details:

Stock# N-D51H14U75

Nanocrystalline Fe-Cu-Nb-Si-B powder core
Composition (at%): 0-1.0 Co, 0.5-1.5 Cu, 2-4 Nb, 20-25 Si+B, bal. Fe
AL: 94 nH/N2
Permeability: 75



Dimensions of Toroidal Cores (mm)



OD (max.)

ID (min.)

H (max.)



Before Coating

50.80

31.75

14.46



After Coating

51.70

30.90

15.35




Magnetic Dimensions

Cross-Sectional Area (Ae)

Magnetic Path Length (Le)

Window

Area (Wa)

Volume (Vol.)

1.251 cm2

12.73 cm

7.50 cm2

15.93 cm3


Magnetic Property

Stock No.

AL (nH/N2)

Permeability m

N-D51H14U26

32

26

N-D51H14U60

75

60

N-D51H14U75

94

75

N-D51H14U90

113

90


  Winding Information

AWG Wire

Single Layer

AWG Wire

Single Layer

No.

Dia. (mm)

Turns

Resistance (mW)

No.

Dia. (mm)

Turns

Resistance (mW)

10

2.67

26

5.51

19

0.980

78

133

11

2.38

30

8.01

20

0.879

88

189

12

2.13

34

11.5

21

0.785

99

269

13

1.90

39

16.5

22

0.701

111

381

14

1.71

43

23.0

23

0.632

124

534

15

1.53

49

33.0

24

0.566

138

752

16

1.37

55

46.9

25

0.505

156

1070

17

1.22

62

66.4

26

0.452

174

1510

18

1.09

70

94.8

27

0.409

193

2100
